UML support is limited to class diagrams and the code-generation capabilities are simple class to class (or interface to interface) transformations. PyUML is an open source Eclipse plug-in offering round-trip engineering between UML and Python. It’s highly configurable, having special pragmas to control its errors and warnings from within your code, as well as from an extensive configuration file. Pylint is a Python static code analysis tool which looks for programming errors, helps enforcing a coding standard, sniffs for code smells and offers simple refactoring suggestions.
PYTHON SEQUENCE DIAGRAM GENERATOR INSTALL
You need to install Graphviz as the pyreverse generates the UML diagrams in dot format and needs the dot.exe provided by Graphviz. If you have anaconda already installed use pip install -U pylint to update the Pylint so that pyreverse is added to the scripts folder. SYNOPSIS pyreverse DESCRIPTION pyreverse is a python source analyzer. Pyreverse Description pyreverse(1) User's Manual pyreverse(1) NAME pyreverse - parse python sources files and extract diagrams from them. Pyreverse is a tool for generating UML diagrams from Python source code.
Pyreverse is a tool in the Pylint tool suite. Since september 2008 it has been integrated with Pylint (0.15). Pyreverse analyses Python code and extracts UML class diagrams and package depenndencies.
